How does it work?
The Carrier is fixed with Grid Accessories at the required spacing and has a present location for Panel Sequence. Powder-coated 150F Panels are then easily connected to the carrier. The system has been designed to maximize design flexibility while maintaining ease of installation. 150F, specially designed arrangement make the Ceiling completely interlocked and airtight for a smooth look & uninterrupted appearance, which can withstand extreme wind pressure.Supersil makes 150F interlockable made out of Alu. / GS of 150 mm wide x 17 mm deep x length up to 5 meters. pre-coated with Alu. / GS Carrier of 34.5 mm wide x 48 mm deep x 0 . 6 0 mm thick with protruding ears to hold the panels in a module of 150mm center to center at a distance of a maximum of 900mm to 1 meter.
Key Features
Round Edge Design
Automated Finished Factory Material
Reduce Dead Load with Lightweight System
Easy Access
Interior Applications only
Compatible with industry Norms
Application
Residential
Commercial buildings.
Transport (Metro, Bus, Railway Station)
Public Space
Hospitality
Health Care
Education
