How does it work?
The Carrier is fixed with Grid Accessories at the required spacing and has a present location for Panel Sequence. Powder-coated 84C Panels are then easily connected to the carrier. The system has been designed to maximize design flexibility while maintaining ease of installation.Supersil makes 84C Round edge panels made out of Alu. / GS of 84mm wide x 15 mm deep x length up to 5mtrs. With 25mm recess flange powder Coated in standard colors, fitted on Alu. / GS carrier of 28 mm wide x 43 mm deep x0.45 mm thick with protruding ears to hold the panels in a module of 100 mm center to center at a distance of a maximum of 1.2 to 1.5 meters.
Key Features
Round Edge Design
Automated Finished Factory Material
Reduce Dead Load with Lightweight System
Easy Access
Interior Applications only
Compatible with industry Norms
Application
Residential
Commercial buildings.
Transport (Metro, Bus, Railway Station)
Public Space
Hospitality
Health Care
Education
